No. Terminal Devices Connection method
2
HDMI Output
• Audio Visual device
• External monitor
• Projector
Use this terminal to output the
image and sounds being played
on the whiteboard to an audio-
visual device, external monitor or
projector.
See page 106 "Using a Projector
to Project a Screen".
3
USB Port
• USB flash memory
device
• Video conferencing
device
See page 31 "Inserting a USB
Flash Memory Device".
See page 102 "Connecting a
Video Conferencing Device to the
Machine".
4
LAN Port
Router or other
communication devices
Use this terminal port to connect
the LAN cable.
5
Audio Output
Self-powered speaker or
other audio device
Use this terminal to connect to the
line input terminal of an amplifier.
6
HDMI Input
• Computer
• Tablet
• Document camera
• Digital still camera
• Digital video camera
You cannot display copyright-
protected content such as DVD
and Blu-ray discs.
See page 99 "Connecting a
Computer or Tablet to the
Machine".
• To display a copyright-
protected material, connect
to the HDMI Input of the
main unit. For the input/
output terminals of the main
unit and other parts of the
machine, see "Read This
First" of RICOH Interactive
Whiteboard D8600.
Devices That Can Be Connected to the Machine
97
