Ricoh Interactive Whiteboard Controller Type 2 User Manual

Item Description
Advanced • Mic. Adjustment
Adjusts the input volume of the microphone.
To enable Microphone Boost, slide the Microphone Gain
bar all the way to the left, and then click the [Microphone
Boost] checkbox. After you enable Microphone Boost, slide
the Microphone Gain bar to the desired level. To achieve
the optimal input volume, slide the Microphone Gain bar to
the recommended input volume area.
If the input volume is low, enable Microphone Boost, and
then increase the volume.
• Output Volume Adjustment
Adjusts the output volume.
Network Settings tab
Item Description
TCP Port (443) If the UDP port cannot be used for communication during a video
meeting due to problems with the network environment, you can
use the TCP port (443) instead.
Limited Bandwidth Usage The network bandwidth used during a meeting can be suppressed
to the minimum required level to prevent the network connection
from becoming overloaded, or to limit the amount of data sent.
This setting cannot be specified during a meeting.
When this mode is used, the image quality of the meeting screen
might deteriorate.
General tab
Item Description
Select Language Select your preferred language.
Version You can check the software version of the RICOH UCS function
that you are using.
4. Connecting to a Video Conference
118

Ricoh Interactive Whiteboard Controller Type 2 Specifications

General

Brand	Ricoh
Model	Interactive Whiteboard Controller Type 2
Category	Controller
Language	English
