Jam Code
SP
Display Description
LCD
Display
7-504-145 FIN Exit Motor (D589)
Stack feed-out belt HP sensor does not turn off
after the stack feed-out belt has moved from
its home position.
Stack feed-out belt HP sensor does not turn on
after the stack feed-out belt has returned to its
home position.
R7-R11
7-504-146
FIN Stack 1 Release
Motor (D589)
Stopper S HP sensor does not turn off after the
stopper S has moved from its home position.
Stopper S HP sensor does not turn on after the
stopper S has returned to its home position.
R7-R11
7-504-147
FIN Stack 2 Release
Motor (D589)
Lower clamp roller HP sensor does not turn off
after the lower clamp roller has moved from
its home position.
Lower clamp roller HP sensor does not turn on
after the lower clamp roller has returned to its
home position.
R7-R11
7-504-148
FIN Stopper Motor
(D589)
Bottom fence HP sensor does not turn off after
the bottom fence has moved from its home
position.
Bottom fence HP sensor does not turn on after
the bottom fence has returned to its home
position.
R7-R11
7-504-160 Entrance Sn:ON (D585) Paper does not reach the entrance sensor. R1
7-504-161 Entrance Sn (D585) Paper stays at the entrance sensor. R1
7-504-162 FIN Entrance (D585) Sensor does not detect paper. R2
7-504-163 Positioning Roller (D585)
Positioning roller HP sensor does not turn off
after the positioning roller has moved from its
home position.
Positioning roller HP sensor does not turn on
after the positioning roller has returned to its
home position.
R1
