Ricoh OR-C1 User Manual

Jam Code
SP
Display Description
LCD
Display
7-504-139
FIN Paper Punch Motor
(D589)
Punch encoder sensor does not turn on/off
after the punch drive motor has turned on.
Punch movement HP sensor does not turn on/
off after the punch movement motor has
turned on.
Paper position slide HP sensor does not turn
on/off after the paper position sensor slide
motor has turned on.
R1-R3
7-504-140
FIN Tray Lift Motor
(D589)
Shift Tray position sensor does not detect
paper after the shift tray has lifted up.
Shift Tray position sensor still detects paper
after the shift tray has moved down.
R1-R3
7-504-141
FIN Jogger Motor
(D589)
Jogger fence HP sensor does not turn off after
the jogger fence has moved from its home
position.
Jogger fence HP sensor does not turn on after
the jogger fence has returned to its home
position.
R7-R11
7-504-142 FIN Shift Motor (D589)
Shift motor HP sensor does not turn off after
the shift roller has moved from its home
position.
Shift motor HP sensor does not turn on after
the shift roller has returned to its home
position.
R1-R3
7-504-143
FIN Fold Plate Motor
(D589)
Fold plate HP sensor does not turn off after the
shift fold plate has moved from its home
position.
Fold plate HP sensor does not turn on after the
s fold plate has returned to its home position.
R7-R11
7-504-144 FIN Staple Motor (D589)
Corner stapler does not finish stapling after a
specified time.
Booklet stapler does not finish stapling after a
specified time.
R7-R11
Jam Detection
337
6
