Jam Code
SP
Display Description
LCD
Display
7-504-109
Finisher Exit Motor
(D588)
Stack belt HP sensor does not turn off after the
stack feed-out belt has moved from its home
position.
Stack feed-out belt HP sensor does not turn on
after the stack feed-out belt has returned to its
home position.
R3-R5
7-504-130 FIN Entrance (D589)
Paper does not reach the entrance sensor or
stay at the entrance sensor.
R1-R3
7-504-131
FIN Proof Tray Exit
(D589)
Paper does not reach the proof tray exit
sensor or stays at the proof tray exit sensor.
R1-R3
7-504-132 FIN Shift Tray (D589)
Paper does not reach the shift tray exit sensor
or stays at the shift tray exit sensor.
R1-R3
7-504-133 FIN Staple Exit (D589)
Paper does not reach the staple tray exit
sensor or stays at the staple tray exit sensor.
R4-R6
7-504-134 FIN Exit (D589) Exit sensor does not detect paper. R4-R6
7-504-135 Finisher Fold (D589)
Paper does not reach the fold unit entrance
sensor or stay at the fold unit entrance sensor.
R7-R11
7-504-136 FIN Fold Exit (D589)
Paper does not reach the fold unit exit sensor
or stay at the fold unit exit sensor.
R7-R11
7-504-137
Exit Guide Gate Motor
(D589)
Exit guide plate HP sensor does not turn off
after the guide plate has moved from its
position.
Exit guide plate HP sensor does not turn on
after the guide plate has returned to its
position.
R1-R3
7-504-138
FIN Staple Shift Motor
(D589)
Stapler unit HP sensor does not turn off after
the stapler unit has moved from its position.
Stapler unit HP sensor does not turn on after
the stapler unit has returned to its position.
R7-R11
6. Troubleshooting
336
6
