Offset Range Meaning Error Code
6-7 X'8000'-
X'7FFF'
GRAPHICS BLOCK ORIGIN Yp, B, or B-offset Coordinate
Position.
See "Notation Conventions", IPDS Technical Reference 1.
8-9 ORIENTATION of Graphic Block X'0203..0
5'
X'0000' 0 degrees
X'2D00' 90 degrees
X'5A00' 180 degrees
X'8700' 270 degrees
10 COORDINATE REFERENCE SYSTEM X'0204..0
5'
X'00' Absolute I, Absolute B
X'20' Absolute I, Relative B
X'40' Relative I, Absolute B
X'60' Relative I, Relative B
X'A0' Page Xp, Yp
11-n Ignored
Graphics Output Control
Offset Range Meaning Error Code
0-1 X'0010'-
X'xxxx'
LENGTH of Graphics Output Control (GOC) X'0202..0
5'
2-3 X'A66B' STRUCTURED FIELD ID X'020B..
05'
4 UNIT BASE (Measurement Units) X'0205..0
5'
X'00' 10 Inches
X'01' 10 Centimeters
5. Graphics Command Set
148
