Offset Range Meaning Error Code
5-6 X'0001' -
X'7FFF'
L-Units per UNIT BASE X'0206..0
5'
7-8 X'0001' -
X'7FFF'
X EXTENT of GRAPHICS BLOCK in L-units
See "Notation Conventions", IPDS Technical Reference 1.
X'0207..0
5'
X'FFFF' Use Load Page Descriptor Value
9-10 X'0001' -
X'7FFF'
Y EXTENT of GRAPHICS BLOCK in L-units
See "Notation Conventions", IPDS Technical Reference 1.
X'0207..0
5'
X'FFFF' Use Load Page Descriptor Value
11 MAPPING Control Option X'0208..0
5'
X'10' Scale to Fit
X'20' Center and Trim
X'30' Position and Trim
12-13 X'8000' -
X'7FFF'
X OFFSET L-units.
See "Notation Conventions", IPDS Technical Reference 1.
X'0209..0
5'
14-15 X'8000' -
X'7FFF'
Y OFFSET L-units.
See "Notation Conventions", IPDS Technical Reference 1.
X'0209..0
5'
Graphics Commands
149
