Rigol DS2000E Series Programming Guide

2 Command System RIGOL
DS2000E Programming Guide
2-93
:CURSor:TRACk:CAX
:CURSor:TRACk:CBX
Syntax
:CURSor:TRACk:CAX <ax>
:CURSor:TRACk:CAX?
:CURSor:TRACk:CBX <bx>
:CURSor:TRACk:CBX?
Description
Set or query the horizontal position of cursor A in track measurement with cursor.
Set or query the horizontal position of cursor B in track measurement with cursor.
Parameter
Name Type Range Default
<ax> Integer 0 to 699 150
<bx> Integer 0 to 699 550
Explanation
The horizontal and vertical positions of the cursor are defined by the pixel coordinate of the screen. The
pixel coordinate of the screen ranges from (0,0) to (700,400). Wherein, (0,0) is located at the left top
corner of the screen, and (700,400) is located at the right bottom corner of the screen. The horizontal
pixel range is from 0 to 699.
Return Format
The query returns an integer between 0 and 699.
:CURSor:TRACk:CAY?
:CURSor:TRACk:CBY?
Syntax
:CURSor:TRACk:CAY?
:CURSor:TRACk:CBY?
Description
Query the vertical position of cursor A in track measurement with cursor.
Query the vertical position of cursor B in track measurement with cursor.
Return Format
The query returns the vertical position of cursor A or cursor B in integer.
