Rigol DS2000E Series - Timebase:delay:offset; Timebase:delay:scale

2 Command System RIGOL
DS2000E Programming Guide
2-239
:TIMebase:DELay:OFFSet
Syntax
:TIMebase:DELay:OFFSet <offset>
:TIMebase:DELay:OFFSet?
Description
Set or query the horizontal offset of the delayed sweep and the unit is s.
Parameter
Name Type Range Default
<offset> Real -(LeftTime - DelayRange/2) to (RightTime - DelayRange/2) 0
Note:
LeftTime = 7 x MainScale - MainOffset
RightTime = 7 x MainScale + MainOffset
DelayRange = 14 x DelayScale
For the MainScale, refer to the
:TIMebase[:MAIN]:SCALe command; for the MainOffset, refer to
the
:TIMebase[:MAIN]:OFFSet command; and for the DelayScale, refer to the :TIMebase:DELay:SCALe command.
Return Format
The query returns the horizontal offset of the delayed sweep in scientific notation.
:TIMebase:DELay:SCALe
Syntax
:TIMebase:DELay:SCALe <scale_value>
:TIMebase:DELay:SCALe?
Description
Set or query the delayed sweep time base, and the unit is s/div.
Parameter
Name Type Range Default
<scale_value> Real (1.25/real-time sample rate) to the current main time base 500ns/div
Note: For the main time base, refer to the :TIMebase[:MAIN]:SCALe command.
Return Format
The query returns the delayed sweep time base in scientific notation.
