Rigol DS2000E Series Programming Guide

RIGOL 2 Command System
2-212 DS2000E Programming Guide
:REFerence:VSCale
Syntax
:REFerence:VSCale <vscale>
:REFerence:VSCale?
Description
Set or query the vertical scale of the current refrence channel waveform. The unit is the same with that of
the current signal source.
Parameter
Name Type Range Default
<vscale> Integer 1 to 10 5
Explanation
Define the vertical scale of the reference channel waveform when performing the store operation as
"Vscale0" and the vertical scale of the reference channel waveform currently set as "Vscale1". Different
<vscale> values are used to represent different ratio relations between Vscale0 and Vscale1, as shown in
the table below.
<vscale> Vscale1/Vscale0
1 0.05
2 0.1
3 0.2
4 0.5
5 1
6 2
7 5
8 10
9 20
10 50
Return Format
The query returns an integer from 1 to 10. If the REF function is currently disabled or no reference
waveform is stored for the current reference channel, the query returns Null.
