2 Command System RIGOL
DS2000E Programming Guide
2-257
:TRIGger:DURATion (Option)
 :TRIGger:DURATion:SOURce
 :TRIGger:DURATion:TLOWer
 :TRIGger:DURATion:TUPPer
 :TRIGger:DURATion:TYPe
 :TRIGger:DURAtion:WHEN
:TRIGger:DURATion:SOURce
Syntax
:TRIGger:DURATion:SOURce <source>
:TRIGger:DURATion:SOURce?
Description
Set or query the trigger source of duration trigger.
Parameter
Name Type Range Default
<source> Discrete {CHANnel1|CHANnel2} CHANnel1
Return Format
The query returns CHAN1 or CHAN2.
:TRIGger:DURATion:TLOWer
Syntax
:TRIGger:DURATion:TLOWer <tlower>
:TRIGger:DURATion:TLOWer?
Description
Set or query the lower limit of the duration time of duration trigger. The unit is s.
Parameter
Name Type Range Default
<tlower> Real
When the trigger condition is GREater: 2ns to 4s
When the trigger condition is GLESs: 2ns to 3.99s
1us
Note: For the trigger condition of duration trigger, please refer to the :TRIGger:DURAtion:WHEN command.
Return Format
The query returns the lower limit of the duration time of duration trigger in scientific notation.
