Rigol DS2000E Series Programming Guide

2 Command System RIGOL
DS2000E Programming Guide
2-319
:WAVeform:FORMat
Syntax
:WAVeform:FORMat <format>
:WAVeform:FORMat?
Description
Set or query the return format of the waveform data.
Parameter
Name Type Range Default
<format> Discrete {WORD|BYTE|ASCii} BYTE
Explanation
 WORD: each waveform point occupies two bytes (namely 16 bits). The lower 8 bits are valid and the
higher 8 bits are 0.
 BYTE: each waveform point occupies one byte (namely 8 bits).
 ASCii: return the voltage value of each waveform point in character value format. The voltage values
are separated by commas.
Return Format
The query returns WORD, BYTE, or ASC.
:WAVeform:POINts
Syntax
:WAVeform:POINts <point>
:WAVeform:POINts?
Description
Set or query the number of waveform points to be read.
Parameter
Name Type Range Default
<point> Integer
NORMal: 1 to 1400
MAXimum: 1 to the number of effective points currently on the
screen
RAW: 1 to the current maximum memory depth
1400
Explanation
The number of waveform points is limited by the current reading mode of waveform (refer to
the
:WAVeform:MODE command).
Return Format
The query returns the number of waveform points to be read in integer.

Rigol DS2000E Series Specifications

General

Bandwidth	70 MHz to 200 MHz
Channels	2 or 4
Vertical Sensitivity	1 mV/div to 10 V/div
Vertical Resolution	8-bit
Timebase Range	2 ns/div to 50 s/div
Memory Depth	14 Mpts
Input Impedance	1 MΩ ± 1%
Trigger Modes	Edge, Pulse, Video
Waveform Capture Rate	50, 000 wfm/s
Interfaces	USB, LAN
Power Supply	100-240 VAC
Display	8-inch WVGA (800x480) LCD
