Rigol DS2000E Series Programming Guide

RIGOL 2 Command System
2-76 DS2000E Programming Guide
:CHANnel<n>:COUPling
Syntax
:CHANnel<n>:COUPling <coupling>
:CHANnel<n>:COUPling?
Description
Set or query the coupling mode of the specified analog channel.
Parameter
Name Type Range Default
<n> Discrete {1|2} --
<coupling> Discrete {AC|DC|GND} DC
Explanation
 AC: the DC components of the signal under test are blocked.
 DC: the DC and AC components of the signal under test can both pass the channel.
 GND: the DC and AC components of the signal under test are both blocked.
Return Format
The query returns AC, DC, or GND.
:CHANnel<n>:DISPlay
Syntax
:CHANnel<n>:DISPlay <bool>
:CHANnel<n>:DISPlay?
Description
Enable or disable the specified analog channel; or query the current status of the specified analog
channel.
Parameter
Name Type Range Default
<n> Discrete {1|2} --
<bool> Bool {{1|ON}|{0|OFF}} 1|ON
Return Format
The query returns 1 or 0.

Rigol DS2000E Series Specifications

General

Bandwidth	70 MHz to 200 MHz
Channels	2 or 4
Vertical Sensitivity	1 mV/div to 10 V/div
Vertical Resolution	8-bit
Timebase Range	2 ns/div to 50 s/div
Memory Depth	14 Mpts
Input Impedance	1 MΩ ± 1%
Trigger Modes	Edge, Pulse, Video
Waveform Capture Rate	50, 000 wfm/s
Interfaces	USB, LAN
Power Supply	100-240 VAC
Display	8-inch WVGA (800x480) LCD
