Rigol DS2000E Series Programming Guide

2 Command System RIGOL
DS2000E Programming Guide
2-81
:CHANnel<n>:VERNier
Syntax
:CHANnel<n>:VERNier <bool>
:CHANnel<n>:VERNier?
Description
Enable or disable the fine adjustment function of the vertical scale of the specified analog channel; or
query the current status of the fine adjustment function of the vertical scale of the specified analog
channel.
Parameter
Name Type Range Default
<n> Discrete {1|2} --
<bool> Bool {{1|ON}|{0|OFF}} 0|OFF
Explanation
By default, the fine adjustment function is disabled. At this point, you can only set the vertical scale in
1-2-5 step; namely 500uV/div, 1mV/div, 2mV/div, 5mV/div, 10mV/div…10V/div. When the fine adjustment
function is enabled, you can further adjust the vertical scale within a relatively smaller range to improve
vertical resolution. If the amplitude of the input waveform is a little bit greater than the full scale under
the current scale, and the amplitude would be a little bit lower if the next scale is used, fine adjustment
can be used to improve the amplitude of waveform display to view signal details.
Return Format
The query returns 1 or 0.
