Rigol DS2000E Series Programming Guide

2 Command System RIGOL
DS2000E Programming Guide
2-275
:TRIGger:PULSe
 :TRIGger:PULSe:LEVel
 :TRIGger:PULSe:LWIDth
 :TRIGger:PULSe:SOURce
 :TRIGger:PULSe:UWIDth
 :TRIGger:PULSe:WHEN
:TRIGger:PULSe:LEVel
Syntax
:TRIGger:PULSe:LEVel <level>
:TRIGger:PULSe:LEVel?
Description
Set or query the trigger level of pulse trigger when the trigger source is CHANnel1, CHANnel2, or EXT.
The unit is the same with the current amplitude unit.
Parameter
Name Type Range Default
<level> Real
When the trigger source is CHANnel1 or CHANnel2:
-5×VerticalScale–OFFSet to +5×VerticalScale–OFFSet
When the trigger source is EXT: -4V to 4V
0
Note: For the VerticalScale, refer to the :CHANnel<n>:SCALe command. For the OFFSet, refer to
the
:CHANnel<n>:OFFSet command.
Explanation
To set the trigger source of pulse trigger, please refer to the
:TRIGger:PULSe:SOURce command.
Return Format
The query returns the trigger level of pulse trigger when the trigger source is CHANnel1, CHANnel2, or
EXT in scientific notation.
