Rigol DS2000E Series Programming Guide

RIGOL 2 Command System
2-132 DS2000E Programming Guide
:MASK:X
:MASK:Y
Syntax
:MASK:X <x>
:MASK:X?
:MASK:Y <y>
:MASK:Y?
Description
Set or query the horizontal adjustment parameter of the pass/fail test mask, and the unit is div.
Set or query the vertical adjustment parameter of the pass/fail test mask, and the unit is div.
Parameter
Name Type Range Default
<x> Real 0.02 to 4, the step is 0.02 0.24
<y> Real 0.04 to 5.12, the step is 0.04 0.48
Return Format
The query returns the horizontal or vertical adjustment parameter of the pass/fail test mask in scientific
notation.
:MASK:CREate
Syntax
:MASK:CREate
Description
Create the mask of the pass/fail test using the horizontal adjustment parameter and the vertical
adjustment parameter currently set.
Explanation
 This command is valid only when the pass/fail test function is enabled (
:MASK:ENABle) and is in
running state (
:MASK:OPERate).
 For the setting of the horizontal adjustment parameter, refer to the
:MASK:X command. For the
setting of the vertical adjustment parameter, refer to the
:MASK:Y command.

Rigol DS2000E Series Specifications

General

Bandwidth	70 MHz to 200 MHz
Channels	2 or 4
Vertical Sensitivity	1 mV/div to 10 V/div
Vertical Resolution	8-bit
Timebase Range	2 ns/div to 50 s/div
Memory Depth	14 Mpts
Input Impedance	1 MΩ ± 1%
Trigger Modes	Edge, Pulse, Video
Waveform Capture Rate	50, 000 wfm/s
Interfaces	USB, LAN
Power Supply	100-240 VAC
Display	8-inch WVGA (800x480) LCD
