Rigol DS2000E Series Programming Guide

RIGOL 2 Command System
2-142 DS2000E Programming Guide
:MEASure:SETup:MAX
:MEASure:SETup:MID
:MEASure:SETup:MIN
Syntax
:MEASure:SETup:MAX <max>
:MEASure:SETup:MAX?
:MEASure:SETup:MID <mid>
:MEASure:SETup:MID?
:MEASure:SETup:MIN <min>
:MEASure:SETup:MIN?
Description
Set or query the upper limit of the threshold level in the auto measurement of the analog channels. The
unit is %.
Set or query the middle value of the threshold level in the auto measurement of the analog channels. The
unit is %.
Set or query the lower limit of the threshold level in the auto measurement of the analog channels. The
unit is %.
Parameter
Name Type Range Default
<max> Integer 7 to 95 90
<mid> Integer 6 to 94 50
<min> Integer 5 to 93 10
Explanation
 The upper limit, middle value and lower limit of the threshold level are expressed in percentage of
the amplitude and are used to define the time, delay, and phase parameters. Setting the threshold
will affect all the time, delay, and phase parameters. You can also use the
:MEASure:SETup:TYPE
command to select the threshold measurement setting.
 The middle value must be set lower than the currently set upper limit and greater than the currently
set lower limit.
Return Format
The query returns the upper limit, middle value, or lower limit of the threshold level in integer.
