Rigol DS2000E Series Programming Guide

RIGOL 2 Command System
2-144 DS2000E Programming Guide
:MEASure:SETup:DSA
:MEASure:SETup:DSB
Syntax
:MEASure:SETup:DSA <sourceA>
:MEASure:SETup:DSA?
:MEASure:SETup:DSB <sourceB>
:MEASure:SETup:DSB?
Description
Set or query the channel source of source A in delay time measurements.
Set or query the channel source of source B in delay time measurements.
Parameter
Name Type Range Default
<sourceA> Discrete {CHANnel1|CHANnel2 } CHANnel1
<sourceB> Discrete {CHANnel1|CHANnel2 } CHANnel2
Explanation
You can use the delay measurement function to measure 4 kinds of delay times between two channels:
source A rising edge-source B rising edge (
:MEASure:RDELay), source A rising edge-source B falling edge
(
:MEASure:R2FDelay), source A falling edge-source B falling edge (:MEASure:FDELay) and source A
falling edge-source B rising edge (
:MEASure:F2RDelay).
Return Format
The query returns CHAN1 or CHAN2.
