Rigol DS2000E Series Programming Guide

RIGOL 2 Command System
2-178 DS2000E Programming Guide
:MEASure:R2FDelay
Syntax1
:MEASure:R2FDelay <chanA>,<chanB>
Description1
Enable the delay (rising edge-falling edge) measurement function between the two specified channels.
Syntax2
:MEASure:R2FDelay? <chanA>,<chanB>
Description2
Enable the delay (rising edge-falling edge) measurement function between the two specified channels
and return the measurement result (the unit is s).
Parameter
Name Type Range Default
<chanA> Discrete {CHANnel1|CHANnel2} --
<chanB> Discrete {CHANnel1|CHANnel2} --
Return Format
The query returns the delay (rising edge-falling edge) measurement result in scientific notation. When
the measurement result is invalid, the query returns 9.9e37.
Example
:MEASure:R2FDelay CHANnel1,CHANnel2
:MEASure:R2FDelay? CHANnel1,CHANnel2
You can use the following commands to enable the delay (rising edge-falling edge) measurement function
between the two specified channels and the statistic function of the measurement results as well as query
the statistic maximum value, minimum value, current value, average value, and standard deviation of the
delay (rising edge-falling edge) measurement results.
 :MEASure:R2FDelay:SMAXimum
 :MEASure:R2FDelay:SMINimum
 :MEASure:R2FDelay:SCURrent
 :MEASure:R2FDelay:SAVerage
 :MEASure:R2FDelay:SDEViation
