Rigol DS2000E Series Programming Guide

2 Command System RIGOL
DS2000E Programming Guide
2-143
:MEASure:SETup:PSA
:MEASure:SETup:PSB
Syntax
:MEASure:SETup:PSA <sourceA>
:MEASure:SETup:PSA?
:MEASure:SETup:PSB <sourceB>
:MEASure:SETup:PSB?
Description
Set or query the channel source of source A in phase deviation measurements.
Set or query the channel source of source B in phase deviation measurements.
Parameter
Name Type Range Default
<sourceA> Discrete {CHANnel1|CHANnel2} CHANnel1
<sourceB> Discrete {CHANnel1|CHANnel2} CHANnel2
Explanation
You can use the phase deviation measurement function to measure 4 kinds of phase deviations between
tow channels: source A rising edge-source B rising edge (
:MEASure:RPHase), source A rising edge-source
B falling edge (
:MEASure:R2FPhase), source A falling edge-source B falling edge (:MEASure:FPHase) and
source A falling edge-source B rising edge (
:MEASure:F2RPhase).
Return Format
The query returns CHAN1 or CHAN2.
