Rigol DS2000E Series

2 Command System RIGOL
DS2000E Programming Guide
2-209
:REFerence<n>:ENABle
Syntax
:REFerence<n>:ENABle <bool>
:REFerence<n>:ENABle?
Description
Turn on or off the specified reference channel; or query the status of the specified reference channel.
Parameter
Name Type Range Default
<n> Discrete {1|2|3|4|5|6|7|8|9|10} --
<bool> Bool {{1|ON}|{0|OFF}}
Ref1: 1|ON
Ref2 to Ref10: 0|OFF
Return Format
The query returns 1 or 0.
:REFerence:COLor
Syntax
:REFerence:COLor <color>
:REFerence:COLor?
Description
Set or query the color of the current reference channel waveform.
Parameter
Name Type Range Default
<color> Discrete {GRAY|GREEn|LBLue|MAGenta|ORANge} GRAY
Explanation
The reference waveform color can be set to GRAY, GREEn, LBLue (light blue), MAGenta, or ORANge.
Return Format
The query returns GRAY, GREE, LBL, MAG, or ORAN.
