Rigol DS2000E Series Programming Guide

RIGOL 2 Command System
2-308 DS2000E Programming Guide
:TRIGger:VIDeo (HDTV Option)
 :TRIGger:VIDeo:MODE
 :TRIGger:VIDeo:LEVel
 :TRIGger:VIDeo:LINE
 :TRIGger:VIDeo:POLarity
 :TRIGger:VIDeo:SOURce
 :TRIGger:VIDeo:STANdard
:TRIGger:VIDeo:MODE
Syntax
:TRIGger:VIDeo:MODE <mode>
:TRIGger:VIDeo:MODE?
Description
Set or query the sync type of video trigger.
Parameter
Name Type Range Default
<mode> Discrete {ODDField|EVENfield|LINE|ALINes} ALINes
Note: When the video standard is HDTV, the sync type could only be set to AllLine or Line Number. For the video
standard, refer to the
:TRIGger:VIDeo:STANdard command.
Explanation
 ODDField: trigger on the rising edge of the first ramp waveform pulse in the odd field.
 EVENfield: trigger on the rising edge of the first ramp waveform pulse in the even field.
 LINE: trigger on the specified line. When this sync trigger mode is selected, you can use
the
:TRIGger:VIDeo:LINE command to specify a line number.
 ALINes: trigger on the first line found.
Return Format
The query returns ODDF, EVEN, LINE, or ALIN.
