Rigol DS2000E Series Programming Guide

2 Command System RIGOL
DS2000E Programming Guide
2-307
:TRIGger:USB:SPEed
Syntax
:TRIGger:USB:SPEed <value>
:TRIGger:USB:SPEed?
Description
Set or query the signal speed of USB trigger
Parameter
Name Type Range Default
<value> Discrete {LOW|FULL} LOW
Return Format
The query returns LOW or FULL.
:TRIGger:USB:WHEN
Syntax
:TRIGger:USB:WHEN <condition>
:TRIGger:USB:WHEN?
Description
Set or query the trigger condition of USB trigger.
Parameter
Name Type Range Default
<condition> Discrete {SOP|EOP|RC|SUSPend|EXITsuspend} SOP
Explanation
 SOP: trigger at the sync bit at the start of the data packet (SOP).
 EOP: trigger at the end of the SEO portion of the EOP of the data packet.
 RC: trigger when SEO is greater than 10ms.
 SUSPend: trigger when the idle time of the bus is greater than 3ms.
 EXITsuspend: trigger when the bus exits from idle state for more than 10ms.
Return Format
The query returns SOP, EOP, RC, SUSP, or EXIT.
