Rigol DS2000E Series Programming Guide

RIGOL 2 Command System
2-194 DS2000E Programming Guide
:MEASure:VPP
Syntax 1
:MEASure:VPP <chan>
Description 1
Enable the peak-peak value measurement function of the specified channel.
Syntax 2
:MEASure:VPP? <chan>
Description 2
Enable the peak-peak value measurement function of the specified channel and return the measurement
result.
Parameter
Name Type Range Default
<chan> Discrete {CHANnel1|CHANnel2|MATH} --
Explanation
The unit is determined by the unit selected for the signal source channel (refer to
the
:CHANnel<n>:UNITs command).
Return Format
The query returns the peak-peak value measurement result in scientific notation. When the measurement
result is invalid, the query returns 9.9e37.
Example
:MEASure:VPP CHANnel1
:MEASure:VPP? CHANnel1
You can use the following commands to enable the peak-peak value measurement function of the
specified channel and the statistic function of the measurement results as well as query the statistic
maximum value, minimum value, current value, average value, and standard deviation of the peak-peak
value measurement results.
 :MEASure:VPP:SMAXimum
 :MEASure:VPP:SMINimum
 :MEASure:VPP:SCURrent
 :MEASure:VPP:SAVerage
 :MEASure:VPP:SDEViation
