Rigol DS2000E Series Programming Guide

2 Command System RIGOL
DS2000E Programming Guide
2-65
:CALCulate:LOGic
 :CALCulate:LOGic:SA
 :CALCulate:LOGic:SB
 :CALCulate:LOGic:INVert
 :CALCulate:LOGic:VSCale
 :CALCulate:LOGic:VOFFset
 :CALCulate:LOGic:OPERator
 :CALCulate:LOGic:ATHReshold
 :CALCulate:LOGic:BTHReshold
:CALCulate:LOGic:SA
:CALCulate:LOGic:SB
Syntax
:CALCulate:LOGic:SA <source>
:CALCulate:LOGic:SA?
:CALCulate:LOGic:SB <source>
:CALCulate:LOGic:SB?
Description
Set or query the channel source of source A in the logic operation.
Set or query the channel source of source B in the logic operation.
Parameter
Name Type Range Default
<source> Discrete {CHANnel1|CHANnel2} CHANnel1
Explanation
If the current logic operation type is NOT, only use the :CALCulate:LOGic:SA command to specify the
channel source of signal source A.
Return Format
The query returns CHAN1 or CHAN2.
