Rigol DS2000E Series Programming Guide

RIGOL 2 Command System
2-66 DS2000E Programming Guide
:CALCulate:LOGic:INVert
Syntax
:CALCulate:LOGic:INVert <bool>
:CALCulate:LOGic:INVert?
Description
Enable or disable the inverted display of the logic operation result; or query the current status of the
inverted display of the logic operation result.
Parameter
Name Type Range Default
<bool> Bool {{1|ON}|{0|OFF}} 0|OFF
Return Format
The query returns 1 or 0.
:CALCulate:LOGic:VSCale
Syntax
:CALCulate:LOGic:VSCale <scale>
:CALCulate:LOGic:VSCale?
Description
Set or query the vertical scale of the logic operation result.
Parameter
Name Type Range Default
<scale> Real 0.05U to 100U 1U
Return Format
The query returns the vertical scale of the logic operation result in scientific notation.

Rigol DS2000E Series Specifications

General

Bandwidth	70 MHz to 200 MHz
Channels	2 or 4
Vertical Sensitivity	1 mV/div to 10 V/div
Vertical Resolution	8-bit
Timebase Range	2 ns/div to 50 s/div
Memory Depth	14 Mpts
Input Impedance	1 MΩ ± 1%
Trigger Modes	Edge, Pulse, Video
Waveform Capture Rate	50, 000 wfm/s
Interfaces	USB, LAN
Power Supply	100-240 VAC
Display	8-inch WVGA (800x480) LCD
