Rigol DS2000E Series

2 Command System RIGOL
DS2000E Programming Guide
2-67
:CALCulate:LOGic:VOFFset
Syntax
:CALCulate:LOGic:VOFFset <offs>
:CALCulate:LOGic:VOFFset?
Description
Set or query the vertical offset of the logic operation result.
Parameter
Name Type Range Default
<offs> Real (-40 x VScale) to (40 x VScale) 0
Note: For the VScale (the vertical scale of MATH), refer to the :CALCulate:LOGic:VSCale command.
Return Format
The query returns the vertical offset of the logic operation result in scientifc notation.
:CALCulate:LOGic:OPERator
Syntax
:CALCulate:LOGic:OPERator <oper>
:CALCulate:LOGic:OPERator?
Description
Set or query the operator of logic operation.
Parameter
Name Type Range Default
<oper> Discrete {AND|OR|NOT|XOR} AND
Return Format
The query returns AND, OR, NOT, or XOR.
