Rigol DS2000E Series Programming Guide

RIGOL 2 Command System
2-68 DS2000E Programming Guide
:CALCulate:LOGic:ATHReshold
:CALCulate:LOGic:BTHReshold
Syntax
:CALCulate:LOGic:ATHReshold <thre>
:CALCulate:LOGic:ATHReshold?
:CALCulate:LOGic:BTHReshold <thre>
:CALCulate:LOGic:BTHReshold?
Description
Set or query the threshold of source A in the logic operation.
Set or query the threshold of source B in the logic operation.
Parameter
Name Type Range Default
<thre> Real (-4 x VerticalScale - OFFSet) to (4 x VerticalScale - OFFSet) 0
Note: For the VerticalScale, refer to the :CHANnel<n>:SCALe command. For the OFFSet, refer to
the
:CHANnel<n>:OFFSet command.
Explanation
If the current logic operation type is NOT, you only need to set the threshold of source A.
Return Format
The query returns the threshold of source A or B of logic operation in scientific notation.

Rigol DS2000E Series Specifications

General

Bandwidth	70 MHz to 200 MHz
Channels	2 or 4
Vertical Sensitivity	1 mV/div to 10 V/div
Vertical Resolution	8-bit
Timebase Range	2 ns/div to 50 s/div
Memory Depth	14 Mpts
Input Impedance	1 MΩ ± 1%
Trigger Modes	Edge, Pulse, Video
Waveform Capture Rate	50, 000 wfm/s
Interfaces	USB, LAN
Power Supply	100-240 VAC
Display	8-inch WVGA (800x480) LCD
