Rigol DS2000E Series Programming Guide

RIGOL 2 Command System
2-80 DS2000E Programming Guide
:CHANnel<n>:PROBe
Syntax
:CHANnel<n>:PROBe <atten>
:CHANnel<n>:PROBe?
Description
Set or query the probe attenuation ratio of the specified analog channel.
Parameter
Name Type Range Default
<n> Discrete {1|2} --
<atten> Discrete
{0.01|0.02|0.05|0.1|0.2|0.5|1|2|5|10|20|
50|100|200|500|1000}
1
Explanation
 After setting the probe ratio, multiply the sampled signal by the specified multiple, and then display
the result (the actual amplitude of the signal will not be affected).
 Setting the probe ratio affects the range of the vertical scale.
Return Format
The query returns the attenuation ratio currently set.
:CHANnel<n>:UNITs
Syntax
:CHANnel<n>:UNITs <units>
:CHANnel<n>:UNITs?
Description
Set or query the amplitude display unit of the specified analog channel.
Parameter
Name Type Range Default
<n> Discrete {1|2} --
<units> Discrete {VOLTage|WATT|AMPere|UNKNown} VOLTage
Return Format
The query returns VOLT, WATT, AMP, or UNKN.
