Rigol DS2000E Series Programming Guide

2 Command System RIGOL
DS2000E Programming Guide
2-265
:TRIGger:IIC:CLEVel
:TRIGger:IIC:DLEVel
Syntax
:TRIGger:IIC:CLEVel <level>
:TRIGger:IIC:CLEVel?
:TRIGger:IIC:DLEVel <level>
:TRIGger:IIC:DLEVel?
Description
Set or query the trigger level of I2C trigger when the channel source of the clock line is CHANnel1 or
CHANnel2. The unit is the same with the current amplitude unit.
Set or query the trigger level of I2C trigger when the channel source of the data line is CHANnel1 or
CHANnel2. The unit is the same with the current amplitude unit.
Parameter
Name Type Range Default
<level> Real (-5 x VerticalScale - OFFSet) to (+5 x VerticalScale - OFFSet) 0
Note: For the VerticalScale, refer to the :CHANnel<n>:SCALe command. For the OFFSet, refer to
the
:CHANnel<n>:OFFSet command.
Explanation
To set the channel sources of the clock line and the data line, please refer to the
:TRIGger:IIC:SCL
and
:TRIGger:IIC:SDA commands respectively.
Return Format
The query returns the trigger level of I2C trigger when the channel source of the clock line or the data line
is CHANnel1 or CHANnel2 in scientific notation.
