Rigol DS2000E Series Programming Guide

2 Command System RIGOL
DS2000E Programming Guide
2-291
:TRIGger:SHOLd:SLOPe
Syntax
:TRIGger:SHOLd:SLOPe <slope>
:TRIGger:SHOLd:SLOPe?
Description
Set or query the edge type of setup/hold trigger.
Parameter
Name Type Range Default
<slope> Discrete {POSitive|NEGative} POSitive
Return Format
The query returns POS or NEG.
:TRIGger:SHOLd:STIMe
Syntax
:TRIGger:SHOLd:STIMe <NR3>
:TRIGger:SHOLd:STIMe?
Description
Set or query the setup time of setup/hold trigger.
Parameter
Name Type Range Default
<NR3> Real 2ns to 1s 50ns
Explanation
 Setup time refers to the period of time that the data stays stable and constant before the clock signal
of the trigger appears.
 This command is available when the hold type (refer to the
:TRIGger:SHOLd:TYPe command) is set
to SETup or SETHOLd.
Return Format
The query returns the setup time of setup/hold trigger in scientific notation.
