Rigol DS2000E Series Programming Guide

RIGOL 2 Command System
2-26 DS2000E Programming Guide
:BUS<n>:RS232:BUSer
Syntax
:BUS<n>:RS232:BUSer <baud>
:BUS<n>:RS232:BUSer?
Description
Set or query the user-defined baud rate of data transmission of RS232 decoding on the specified bus. The
default unit is bps.
Parameter
Name Type Range Default
<n> Discrete {1|2} --
<baud> Integer 110 to 20000000 9600
Return Format
The query returns the user-defined baud rate of data transmission of RS232 decoding on the specified
bus in integer.
:BUS<n>:RS232:DBITs
Syntax
:BUS<n>:RS232:DBITs <bits>
:BUS<n>:RS232:DBITs?
Description
Set or query the number of bits of data of RS232 decoding on the specified bus.
Parameter
Name Type Range Default
<n> Discrete {1|2} --
<bits> Discrete {5|6|7|8|9} 8
Return Format
The query returns 5, 6, 7, 8, or 9.

Rigol DS2000E Series Specifications

General

Bandwidth	70 MHz to 200 MHz
Channels	2 or 4
Vertical Sensitivity	1 mV/div to 10 V/div
Vertical Resolution	8-bit
Timebase Range	2 ns/div to 50 s/div
Memory Depth	14 Mpts
Input Impedance	1 MΩ ± 1%
Trigger Modes	Edge, Pulse, Video
Waveform Capture Rate	50, 000 wfm/s
Interfaces	USB, LAN
Power Supply	100-240 VAC
Display	8-inch WVGA (800x480) LCD
