Rigol DS2000E Series Programming Guide

2 Command System RIGOL
DS2000E Programming Guide
2-35
:BUS<n>:SPI:SCLK:SLOPe
Syntax
:BUS<n>:SPI:SCLK:SLOPe <pos>
:BUS<n>:SPI:SCLK:SLOPe?
Description
Set or query the clock edge type of SPI decoding on the specified bus.
Parameter
Name Type Range Default
<n> Discrete {1|2} --
<pos> Discrete {POSitive|NEGative} POSitive
Return Format
The query returns POS or NEG.
:BUS<n>:SPI:SCLK:THReshold
Syntax
:BUS<n>:SPI:SCLK:THReshold <thre>
:BUS<n>:SPI:SCLK:THReshold?
Description
Set or query the clock channel threshold of SPI decoding on the specified bus.
Parameter
Name Type Range Default
<n> Discrete {1|2} --
<thre> Real (-5 x VerticalScale - OFFSet) to (+5 x VerticalScale - OFFSet) 0
Note: For the VerticalScale, refer to the :CHANnel<n>:SCALe command. For the OFFSet, refer to
the
:CHANnel<n>:OFFSet command.
Return Format
The query returns the clock channel threshold of SPI decoding on the specified bus in scientific notation.
