- Press BY, then rotate the multifunction knob to adjust the vertical
position (Y-axis) of Cursor B (Y cursor).
Enable the touch screen and tap BY to set the vertical position of Cursor B (Y
cursor) with the pop-up numeric keypad. The vertical axis indicates voltage,
and the unit of its setting value is the same as that of the vertical unit.
- Press AY BY, then rotate the multifunction knob to adjust the vertical
positions (Y-axis) of Cursor A and Cursor B (Y cursors). The vertical spacing
between Cursor A and Cursor B (Y cursors) remains unchanged.
NOTE
If one of the three menu items (AX, BX, and AX BX) is selected; or one of the three menu
items (AY, BY, and AY BY) is selected; you can press down the multifunction knob
continuously to switch among the three items.
4. Set the Horizontal/Vertical Measurement Unit
- When "X-X" or "XY-X" is selected, you can set the horizontal measurement unit.
When the source is set to Math1-Math4, this menu is grayed out and disabled.
Press More > Hori. Unit, then rotate the multifunction knob to select the
horizontal measurement unit, and then press down the knob to select it. You
can also press
Hori. Unit continuously or enable the touch screen to select it.
The available units include "s", "Hz", "Degree(°)", and "Percent(%)".
- s: measures the time value at X Cursor (taking the trigger position as
reference). The measurement results include AX, BX, ∆X, and 1/∆X. Wherein,
AX, BX, and ∆X all indicate time, and 1/∆X indicates frequency.
- Hz: measures the frequency value at X Cursor (taking the trigger position as
reference). The measurement results include AX, BX, ∆X, and 1/∆X. Wherein,
AX, BX, and ∆X all indicate frequency, and 1/∆X indicates time.
- Degree(°): measures the phase value at X Cursor. The measurement results
include AX, BX, and ∆X, and they are all expressed in degree.
This oscilloscope allows you to set the phase reference position according to
your needs. After adjusting X Cursor to a desired position, press
Set
Reference to take the current cursor position as the reference. The current
positions of Cursor A and Cursor B are respectively defined as "0°" and
"360°". Meanwhile, two vertical cursors (in blue) that cannot be moved are
