continuously or enable the touch screen to select it. The available source channels
are NONE, CH1-CH4, LA, and Math1-Math4.
NOTE
- Only channels currently enabled can be selected.
- When "LA" is selected as the channel source, Select is grayed out and disabled. By
default, "X" is selected under Select.
3.
Adjust the Cursor Position
a. When "X-X" or "XY-X" is selected, you can adjust the position of X cursors.
- Press AX, then rotate the multifunction knob to adjust the horizontal
position (X-axis) of Cursor A (X cursor). Its adjustable range is limited within
the screen.
Enable the touch screen and tap
AX to set the horizontal position of Cursor
A (X cursor) with the pop-up numeric keypad. The horizontal axis indicates
time, and the unit of its setting value is the same as that of the horizontal
unit.
- Press
BX, then rotate the multifunction knob to adjust the horizontal
position (X-axis) of Cursor B (X cursor). Its adjustable range is limited within
the screen.
Enable the touch screen and tap BX to set the horizontal position of Cursor B
(X cursor) with the pop-up numeric keypad. The horizontal axis indicates
time, and the unit of its setting value is the same as that of the horizontal
unit.
- Press
AX BX, then rotate the multifunction knob to adjust the horizontal
positions (X-axis) of Cursor A and Cursor B (X cursors). Its adjustable range is
limited within the screen. The horizontal spacing between Cursor A and
Cursor B (X cursors) remains unchanged.
b. When "Y-Y" or "XY-Y" is selected, you can adjust the position of Y cursors.
- Press AY, then rotate the multifunction knob to adjust the vertical
position (Y-axis) of Cursor A (Y cursor).
Enable the touch screen and tap AY to set the vertical position of Cursor A (Y
cursor) with the pop-up numeric keypad. The vertical axis indicates voltage,
and the unit of its setting value is the same as that of the vertical unit.
Operations and Measurements
