- Y: tracks Y Cursor and measures the time of the first point at the left side of the
screen.
3.
Adjust the Cursor Position
a. When "X" is selected for the track mode, you can adjust the position of X cursor.
- Press AX, then rotate the multifunction knob to adjust the horizontal
position (X-axis) of Cursor A (X cursor). Its adjustable range is limited within
the screen.
- Press BX, then rotate the multifunction knob to adjust the horizontal
position (X-axis) of Cursor B (X cursor). Its adjustable range is limited within
the screen.
- Press AX BX, then rotate the multifunction knob to adjust the horizontal
positions (X-axis) of Cursor A and Cursor B (X cursors). Its adjustable range is
limited within the screen. The horizontal spacing between Cursor A and
Cursor B (X cursors) remains unchanged.
b. When "Y" is selected for the track mode, you can adjust the position of Y cursor.
- Press AY, then rotate the multifunction knob to adjust the vertical
position (Y-axis) of Cursor A (Y cursor).
- Press BY, then rotate the multifunction knob to adjust the vertical
position (Y-axis) of Cursor B (Y cursor).
- Press AY BY, then rotate the multifunction knob to adjust the vertical
positions (Y-axis) of Cursor A and Cursor B (Y cursors). The vertical spacing
between Cursor A and Cursor B (Y cursors) remains unchanged.
NOTE
- If one of the three menu items (AX, BX, and AX BX) is selected; or one of the three
menu items (AY, BY, and AY BY) is selected; you can press down the multifunction knob
continuously to switch among the three items.
- In track mode, the horizontal cursor (or vertical cursor) will track the marked point in a
timely manner (i.g, the cursor will move up and down with the transient change of the
waveform). Thus, the X value (or Y value) might change even though you do not adjust
the cursor.
