Rockwell Automation Allen-Bradley Kinetix 5500

Rockwell Automation Publication 2198-UM001M-EN-P - November 2022 103
Chapter 6 Configure and Start the Kinetix 5500 Drive System
Table 56 - Navigating the Settings Menu
Settings Menu Selections Sub Menu Selections Attributes Default Description
Protected Mode
Reset
ENABLED
DISABLED
ENABLED
When Enabled (default), identity object or safety
resets are not possible when a controller connection
is open.
Network Config
ENABLED
DISABLED
ENABLED
When Enabled (default), network configuration
changes are not possible when a controller
connection is open.
Flash Update
ENABLED
DISABLED
ENABLED
When Enabled (default), firmware updates are not
possible when a controller connection is open.
Device Config
ENABLED
DISABLED
ENABLED
When Enabled (default), only attribute writes are
possible when a controller connection is open.
Network
->Static IP
(1)
IP address 192.168.1.1 Indicates current IP address
Subnet mask 255.255.255.000 Indicates current subnet mask
Gateway 192.168.001.001 Indicates current gateway
DHCP
On Turns on DHCP
Off Turns off DHCP
Display
Backlight Timeout
30 sec…NEVER
(NEVER=no timeout period,
the backlight is always on)
-> 3 min
(1)
Sets backlight timeout period of the display
Cyclic Data Select
(2)
->DC BUS
(1)
DC bus voltage
CONV UTIL Converter utilization in percent
CONV TEMP Converter temperature in °C
SHUNT UTIL Shunt utilization in percent
INV UTIL Inverter utilization in percent
INV TEMP Inverter temperature in °C
MOTOR UTIL Motor utilization in percent
SPEED RPM
OUT PWR Output power in watts
OUT FREQ Output frequency in hertz
OUT CUR Output current in amps
Contrast -10…+10 0 Contrast setting of the display
Safety
(3)
Reset Ownership Are you sure? Resets safety ownership (reset fails after 30 seconds)
Web
Enabled Enables the web server
->Disabled Disables the web server
(1) An arrow (->) appears in front of the chosen attribute indicating that this attribute is currently configured. This is also the factory default setting.
(2) The DC bus voltage is one of several cyclic data attributes. You can select any of the Cyclic Data Select attributes to be displayed on the Home screen.
(3) The Safety menu applies to only 2198-Hxxx-ERS2 drives.
