Rockwell Automation Allen-Bradley Kinetix 5500

32 Rockwell Automation Publication 2198-UM001M-EN-P - November 2022
Chapter 2 Plan the Kinetix 5500 Drive System Installation
Shared DC (common-bus) Drive Systems
Shared AC Drive Systems
Table 10 - Shared DC Drive System Specifications for UL and IEC (non-UL) Applications
Kinetix 5500 Drives UL Applications IEC (non-UL) Applications
Drive Cat. No.
Drive Voltage
(three-phase),
Nom
Bussmann
Fuses
Cat. No.
Molded Case CB Cat. No.
DIN gG Fuses
Amps (max)
Molded Case CB Cat. No.
2198-H003-ERSx 240/480V KTK-R-10 140U-D6D3-C15 and 140UT-D7D3-C15 10 140U-D6D3-C15 and 140UT-D7D3-C15
2198-H008-ERSx 240/480V KTK-R-10 140U-D6D3-C15 and 140UT-D7D3-C15 10 140U-D6D3-C15 and 140UT-D7D3-C15
2198-H015-ERSx 240/480V KTK-R-15 140U-D6D3-C15 and 140UT-D7D3-C15 16 140U-D6D3-C15 and 140UT-D7D3-C15
2198-H025-ERSx 240/480V KTK-R-20 140U-D6D3-C20 and 140UT-D7D3-C20 20 140U-D6D3-C20 and 140UT-D7D3-C20
2198-H040-ERSx 240/480V KTK-R-25 140U-D6D3-C25 and 140UT-D7D3-C25 25 140U-D6D3-C25 and 140UT-D7D3-C25
2198-H070-ERSx 240/480V LPJ-35SP 140G-G6C3-C40 35 140G-G6C3-C40
Table 11 - Input Power UL Circuit-protection Specifications
Kinetix 5500 Drives Bussmann Fuses Cat. No. Molded Case CB Cat. No.
Drive Cat. No.
Drive Voltage
(three-phase),
Nom
2 Axes 3 Axes 4 Axes 5 Axes 2 Axes 3 Axes 4 Axes 5 Axes
2198-H003-ERSx 240/480V KTK-R-15 140U-D6D3-C15 and 140UT-D7D3-C15
2198-H008-ERSx 240/480V KTK-R-15 140U-D6D3-C15 and 140UT-D7D3-C15
2198-H015-ERSx 240/480V KTK-R-20 KTK-R-25 —
140U-D6D3-C15 and
140UT-D7D3-C15
140U-D6D3-C20 and
140UT-D7D3-C20
—
2198-H025-ERSx 240/480V KTK-R-30 —
140U-D6D3-C25 and
140UT-D7D3-C25
140U-D6D3-C30 and
140UT-D7D3-C30
—
2198-H040-ERSx 240/480V LPJ-35SP LPJ-45SP — 140G-G6C3-C40 140G-G6C3-C50 —
2198-H070-ERSx 240/480V LPJ-60SP — 140G-G6C3-C60 —
Table 12 - Input Power IEC (non-UL) Circuit-protection Specifications
Kinetix 5500 Drives DIN gG Fuses, Amps (max) Molded Case CB Cat. No.
Drive Cat. No.
Drive Voltage
(three-phase),
Nom
2 Axes 3 Axes 4 Axes 5 Axes 2 Axes 3 Axes 4 Axes 5 Axes
2198-H003-ERSx 240/480V 16 140U-D6D3-C15 and 140UT-D7D3-C15
2198-H008-ERSx 240/480V 16 140U-D6D3-C15 and 140UT-D7D3-C15
2198-H015-ERSx 240/480V 20 25 —
140U-D6D3-C15 and
140UT-D7D3-C15
140U-D6D3-C20 and
140UT-D7D3-C20
—
2198-H025-ERSx 240/480V 32 —
140U-D6D3-C25 and
140UT-D7D3-C25
140U-D6D3-C30 and
140UT-D7D3-C30
—
2198-H040-ERSx 240/480V 35 50 140G-G6C3-C40 140G-G6C3-C50 —
2198-H070-ERSx 240/480V 63 — 140G-G6C3-C60 —
