Rockwell Automation Publication 2198-UM001M-EN-P - November 2022 45
Chapter 3
Mount the Kinetix 5500 Drive System
This chapter provides the system installation procedures for mounting your
Kinetix® 5500 drives to the system panel.
This procedure assumes you have prepared your panel and understand how to
bond your system. For installation instructions regarding equipment and
accessories that are not included here, refer to the instructions that came with
those products.
Topic Page
Determine Mounting Order 46
Drill-hole Patterns 49
Mount Your Kinetix 5500 Drive 56
SHOCK HAZARD: To avoid a hazard of electrical shock, perform all mounting
and wiring of the Kinetix 5500 drives before applying power. Once power is
applied, connector terminals can have voltage present even when not in
use.
ATTENTION: Plan the installation of your system so that you can perform all
cutting, drilling, tapping, and welding with the system removed from the
enclosure. Because the system is of the open type construction, be careful
to keep metal debris from falling into it. Metal debris or other foreign matter
can become lodged in the circuitry and result in damage to the components.
