Remote Control
R&S
®
RTM20xx
314User Manual 1317.4726.02 ─ 01
TRIGger:B:HYSTeresis <Hysteresis>
Sets a hysteresis range around the trigger level of the B trigger event. If the signal jitters
inside this range and crosses the trigger level thereby, no trigger event occurs.
Parameters:
<Hysteresis> AUTO | SMALl | MEDium | LARGE
*RST: AUTO
15.2.6 Display
15.2.6.1 Basic Display Settings
This chapter describes commands that configure the screen display.
General Display Settings
DISPlay:MODE..............................................................................................................314
DISPlay:PALette............................................................................................................314
DISPlay:MODE <Mode>
Sets the diagram mode.
Parameters:
<Mode> YT | XY
YT
Default time diagram with a time axis in x-direction and the signal
amplitudes displayed in y-direction.
XY
XY-diagram, combines the voltage levels of two waveforms in one
diagram.
*RST: YT
DISPlay:PALette <Palette>
Sets the color and brightness of the displayed waveform samples depending on their
cumulative occurance.
Command Reference
