Search
R&S
®
RTM20xx
147User Manual 1317.4726.02 ─ 01
Start
Sets the start time of the search area in relation to the trigger point.
Remote command:
SEARch:GATE:ABSolute:START on page 361
Stop
Sets the end time of the search area in relation to the trigger point.
Remote command:
SEARch:GATE:ABSolute:STOP on page 361
10.3.10 Events Menu
Access: SEARCH MENU > "Events"
Events are the search results which are marked in the waveform diagram and listed in
the event table. See also: chapter 10.1.1, "Search Results", on page 132.
View event table
Shows or hides the table of search results.
Remote command:
SEARch:RESDiagram:SHOW on page 372
Mark events
Sets markers to the first search results. Up to 20 markers can be set at once.
Clear all event marks
Removes all markers from search results.
Track event
If enables, the selected result is moved to the reference point. Thus you can always see
the selected event in the diagram.
Reference for Search Menu
