8 | Functions and settings
Page 44 of 104 CIRUS
®
UPT-6400 VERSION 1 | EN-US
Menu
num-
ber
Menu
item
Available
only
when the
timer is
activated
(menu
number
401)
Description Setting range
411 Function
of input 1
(CH1)
How input 1 (CH1) (terminals 39+40) functions can be set
here.
• External alarm: An external monitoring device can be
incorporated. The temperature controller detects an
error if the level is HIGH.
• Measurement pause: The measurement pause of the
temperature controller is activated.
• External switch
• Release pulse: The input controls the release pulse
• OFF: Function switched off
The CH1 input can also be used as an analog tempera-
ture input for the AUTOCAL function (menu number 13)
or for the TCR calculator (menu number 303). In this
case, select OFF in menu number 411.
• External alarm
• Measurement
pause
• External switch
• Release pulse
• OFF
413 Restart
delay af-
ter reset
Adjust the restart time after a RESET signal. Can be ad-
justed for contactors that switch slowly.
Refer to section Restart delay after reset [}58] for fur-
ther information.
0.00…9.98sec
414 De-
bouncing
time of
external
switch
The debouncing time for external switches can be set in
this menu item. The inputs DETACH and CH1 can be
used as external switches.
The debouncing time can be used e.g. to debounce
switches on the heat-sealing band.
0.00…2.00sec
422 Release
pulse
Specify whether the temperature controller should gener-
ate a release pulse.
Refer to section Release pulse for further information.
• OFF
• Internal
• External
Diagnosis menu
Menu
num-
ber
Menu
item
Available
only
when the
timer is
activated
(menu
number
401)
Description Setting range
501 Setpoint
reached
If the actual value is higher than the switching threshold
specified here and lower that the switching threshold set
in menu number502, outputA1, relayK1 and/or relayK2
can be activated if configured accordingly (menu num-
bers 407, 408 and 409).
The value is stated in Kelvin(K) and is added to the set-
point to calculate the temperature threshold.
-3…-99K
