Ropex CIRUS UPT-6400 - Page 45

Functions and settings | 8
VERSION 1 | EN-US CIRUS
®
UPT-6400 Page 45 of 104
Menu
num-
ber
Menu
item
Available
only
when the
timer is
activated
(menu
number
401)
Description Setting range
502 Setpoint
ex-
ceeded
If the actual value is lower than the switching threshold
specified here and higher that the switching threshold set
in menu number501, outputA1, relayK1 and/or relayK2
can be activated if configured accordingly (menu num-
bers 407, 408 and 409).
The value is stated in Kelvin(K) and is added to the set-
point to calculate the temperature threshold.
+3…+99K
503 Temper-
ature di-
agnosis
If this value is set to ON, an alarm with error code
307/308 is generated when the temperature leaves the
tolerance range.
• OFF
• ON
504 Temper-
ature di-
agnosis
delay
The delay begins as soon as the actual temperature is
within the temperature tolerance range.
The temperature tolerance with alarm generation is not
active until this time has elapsed.
Available only when temperature diagnosis (menu num-
ber 503) is switched on.
0.00…9.98sec
505 Heatup
timeout
If the actual temperature is not within the temperature tol-
erance range when the time (after activation of the
START signal) set here has elapsed, an alarm with error
code 304 is generated.
• OFF
• 0.02…99.98sec
506 Maxi-
mum
start
tempera-
ture per-
mitted
Maximum temperature permitted upon START.
Refer to section Maximum start temperature [}65] for
further information.
20°C … maximum
temperature (menu
number 306)
507 Closing
time
monitor-
ing
Monitoring of the time between when a external switch
closes the heat-sealing band and activation of the
START signal.
Refer to section Closing time monitoring for further infor-
mation.
• OFF
• 0.02…2.00sec
508 Source
of diag-
nosis
tempera-
ture
The temperature sensor for the diagnosis temperature to
be used can be specified here.
Refer to section Temperature tolerance for further infor-
mation.
• External (set-
point) (analog in-
put, terminals
36+39)
• External (CH1,
terminals 39+40)
• OFF
509 Minimum
diagno-
sis tem-
perature
Minimum diagnosis temperature (from one of the analog
sources, determined by menu number 508). If the tem-
perature falls below the threshold, error code 827 ap-
pears.
Available only when the diagnosis temperature is active
(menu number508).
-99…999°C
