Rotax 125 Micro MAX User Manual

DK00024.fm
REPAIR MANUAL
BRP-Powertrain
Effectivity: 125 MAX/125 Junior MAX/125 Mini
MAX/125 Micro MAX
Edition 2 / Rev. 0
Chapter 2
Page 10
December 01/2010
Figure 2 K00001
No. part no. Description
1 277380 Fixation tool for crankshaft
2 277362 Fixation, tool for sprocket
3 276016 Puller assy.
4 676010 Insertion sleeve
5 676021 Insertion jig
6 676030 Insertion jig
7 676040 Insertion jig
8 676035 Insertion tool
9 877930 Trestle support assy.
10 676052 Fixing plate for engine
11 297040 ROTAX-Seal
12 251680 Spring hook
13 676205 Fixation tool assy.
14 276050 Crankshaft repair jig
15 277390 Combustion chamber insert template
16 277395 Exhaust port height template
17 277397 Exhaust port height template
18 277030 Exhaust valve gauge
19 297240 Engine passport
20 580132 Tin wire 3 mm
21 580130 Tin wire 2 mm
22 276070 Assembly tool bellow spring exhaust
23 277364 Fixation, tool for sprocket
24 676110 Wrench adapter 11/8
25 976380 Monohook circlip remover
