12.7 Meta Corrections
The meta corrections panel (Figure 76) allows including an additional meta bar or meta
pad.
Meta Bar
Left/Right enables the inclusion of a meta bar. This option is only
available if an ortho base type insole has been chosen in
the insole composition panel.
Height controls the height of the chosen meta bar (ranging from 1
to 3 mm in steps of 1 mm).
Lateral Edge
Lateral edge controls the height of the lateral edge (Standard and Low).
Meta Pad
Shape controls the shape of the meta pad (Teardrop and T-
shape).
Height controls the height of the chosen meta pad (ranging from 1
to 5 mm in steps of 1 mm).
Figure 76: Meta Corrections.
