The exported csv file can easily be imported into any currently available spreadsheet

software. The list export takes the user locale of the operating system into account so

that there are no conversion errors between footscan 9 and the spreadsheet software.

Click the Export button to start the export. Click the Close button to close the list

export dialog.
