0.5m plate

1m plate

2m plate

Interface box

Analog coaxial cable 6m (An optional longer cable is

available if required).

USB cable A-B 5m

Power supply unit

Power cord (Specific country version according to order).

A footscan security dongle is a USB2 hardware dongle which can be used to run the

footscan 9 software without a footscan plate being plugged in.

® ®

RS-PRD-00562-016 9
