2. Expand the tree to view the destination devices available.
3. Select the desired device for the destination.
4. Click OK.
The screen closes.
5. Select the channel to which the device connects.
i
Notice!
Be sure to configure the DBP channel to the configured ODIN channel. For example, if ODIN
channel 5 is configured for DBP channel 1, then DBP channel 1 should be configured to ODIN
channel 5.
6. (Optional) Enter the channel description.
Using the Device Configuration Pane
1. (Optional) Enter a description for the device.
2. Send the changes to the device.
6.5 Create connections using AZedit
6.5.1 Configure OMS/ODIN to make a connection offer
Ethernet configuration must be done before an OMNEO channel connection is made.
To configure an OMS/ODIN to make a connection offer, do the following:
1. On the KP screen, select the port (2) to configure the connection.
i
Notice!
If configuring OMS to make connections, you must select an OMNEO port from the Port Alpha
fields (2).
2. Click the Edit button (1).
The Keypanel/Port Configuration screen opens.
