28 en | Basic Operation DBP Digital Beltpack
2021-06 | 01 | F.01U.380.825
Technical Manual
Bosch Security Systems, LLC
Enters a sub-menu, activates a menu item, or saves
changes to an activated menu item (applies to the shaft
encoder as a push button).
SEL/MENU button Enters the menu from the home screen.
Selects a sub-menu from the main menu.
Activates the selected menu item.
Saves changes in an activated menu item and
deactivates the menu item.
Dismisses popup notifications.
Confirms choice in some popup dialogs.
CLR/BACK button Shows or hides the CWW window from the home
screen.
Exits the menu (or moves back one level in the menu if
in a sub-menu).
Discards changes in an activated menu item.
Dismisses popup notifications.
Declines/aborts choice in some popup dialogs.
Displays the Connection state.
CALL button Generates outgoing CALL signals.
Acts as the SHIFT key in KP mode to allow toggling of
listen key states.
1. In some activated menu items, the A/C and B/D shaft encoders behave differently. Specifically, when editing device/domain names or IP addresses, the A/C
shaft encoder moves the cursor between letters or octets and the B/D shaft encoder change the value of the currently highlighted letter/octet. Similarly, in the
Mixer menu, the A/C shaft encoder selects the input to modify for the currently active output, and the B/D shaft encoder enables/disables the mix from the
selected input to the active output.
To enter and navigate the menu structure, do the following:
1. Press the SEL/MENU button.
The main menu structure appears in the display.
2. Rotate either shaft encoder to navigate through the menu.
3. Click the B/D shaft encoder to select a menu item
OR
Press the SEL/MENU button to select a menu item.
4. Click the A/C shaft encoder to back out of a menu
OR
Press the CLR/BACK button to back out of a menu.
8.3 Hot keys
HOME screen:
Press and release the
SEL/MENU button
Enter menu mode.
Press and release the
CLR/BACK button
Displays the CWW.
Press CLR/BACK to dismiss the CWW.
Press and hold the CALL
button (in PL Mode)
Initiates an outgoing CALL signal for
whichever Talk keys are currently on with PL
assignments. The CALL signal lasts until you
release the CALL button
