Operating Instructions Cubis
®
MCE 51
System Settings
Parameters Setting values Explanations
HANDSHK. SOFTWARE Sets the handshake protocol to software handshake.
HARDWARE* Sets the handshake protocol to hardware handshake.
NONE Does not set a handshake protocol.
DATABIT 7 BITS Sets the number of data bits to 7.
8 BITS* Sets the number of data bits to 8.
* Factory setting
Parameters in the “PC-USB” Submenu
Parameters Setting values Explanations
DAT.REC. SBI.WEIGH. Enables a faster SBI communication, only for software commands to the
weighing module.
XBPI Extended range of commands to control numerous balance functions with
binary protocol for direct communication with the weighing module.
SBI* − Enables SBI communication.
− The data is output to a PC or control unit. Enables the use of ESC
commands from a PC to control the basic balance functions with ASCII
protocol.
PC.SPREAD. Enables data output to a spreadsheet program via a direct PC connection.
PC.TEXT Enables a direct PC connection to be established to a text processing
program.
OFF Deactivates the data output.
BAUD 600 Sets the baud rate to 600 baud.
1200 Sets the baud rate to 1200 baud.
2400 Sets the baud rate to 2400 baud.
4800 Sets the baud rate to 4800 baud.
9600* Sets the baud rate to 9600 baud.
19200 Sets the baud rate to 19200 baud.
38400 Sets the baud rate to 38400 baud.
57600 Sets the baud rate to 57600 baud.
115200 Sets the baud rate to 115200 baud.
PARITY ODD* Applies an odd parity.
EVEN Applies an even parity.
NONE Does not apply a parity.
HANDSHK. HARDWARE Sets the handshake protocol to hardware handshake.
NONE* Does not set a handshake protocol.
DATABIT 7 BITS Sets the number of data bits to 7.
8 BITS* Sets the number of data bits to 8.
* Factory setting
